FOX Telaston iskarit: FOX Float 3 QS3/QSL-QSR LW Lynx Boondocker DS 3900/4100
Sopii myös Lynx Boondocker DS 3900/4100
Tuotekoodi: 971-853-21-016
Kauhajoki
Närpiö
Tervajoki
Tampere
LOUKKO.COM TILI
Kuukausierä 156,87 €,
Maksuaika 12 kk,
Luottosumma 1811,70 €,
Vuosikorko 0,00 %,
Käsittelymaksu 5,90 €,
Tod. vuosikorko 3,87 %.
Adjustments:
FLOAT air spring
EVOL air chamber
QS33 position compression (front track), with lockout mode (rear track)
QSR3 position rebound
Features:
Optimized lightweight shock design
Spiral groove bypass
One-piece, aluminum spherical bearings
High-flow velocity-sensitive damping
Fully re-buildable and re-valvable
Air Spring Pressures:
Front Track Main - 35psi
Rear Track Main - 145psi
EVOL - 280psi
Top Mount: Eyelet
Bottom Mount: Eyelet
Rebuild P/n: FT: 803-01-572; RT: 803-01-574
Reservoir: Piggyback
Front Track Extended Length: 13.8800
Front Track Compressed Length: 10.2400
Front Track Travel: 6.0700
Rear Track Extended Length: 13.8800
Rear Track Compressed Length: 15.6100
Rear Track Travel: 6.0700
Fitment notes: Track (Front & Rear)
